427-0026-01-10, version 110 Oct 2010 iii
Table of Contents
1 Warnings and Cautions
2 Introduction
3 Getting Started
3.1 Parts List .................................................................... 5
3.2 Operational Overview ..................................................... 5
3.3 Installation ................................................................... 6
3.3.1 Camera Mounting ................................................ 8
3.3.2 Fuse and Joystick Control Unit Mounting ............... 11
3.4 Using your PatrolIR B .................................................. 13
3.4.1 Joystick Control Unit (JCU) .................................. 13
4 Caring for your PatrolIR B
4.1 Troubleshooting ......................................................... 17
4.2 Replacing the fuses .................................................... 17
4.2.1 Cleaning ........................................................... 18
5 Optional Accessories
5.1 Optional JCUs and Extension Cables ............................. 19
6 Technical Data
6.1 Performance Specifications .......................................... 21
7 Mounting Templates
7.1 Camera Mounting Template. ........................................ 23
7.2 Joystick Control Unit Mounting Template. ....................... 25
PatrolIR B Pan and Tilt User’s Guide
