Technical data24
Laser pointer
Laser Activated by dedicated button
Laser alignment Position is automatic displayed on the IR image
Laser classification Class 2
Laser type
Semiconductor AlGaInP diode laser
Laser power 1 mW
Laser wavelength 635 nm (red)
Data communication interfaces
Interfaces USB-mini, USB-A, Bluetooth, Wi-Fi, composite
video
METERLiNK/Bluetooth Communication with headset and external sensors
Wi-Fi Peer to peer (ad hoc) or infrastructure (network)
SD Card One card slot for removable SD memory cards
USB
USB
• USB-A: Connect external USB device
• USB Mini-B: Data transfer to and from PC / un-
compressed colorized video
USB, standard USB Mini-B: 2.0
Composite video
Video out
Composite
Video, standard
CVBS (ITU-R-BT.470 PAL/SMPTE 170M NTSC)
Video, connector type 4-pole 3.5 mm jack
Radio
Wi-Fi
• Standard: 802.11 b/g
• Frequency range: 2412–2462 MHz
• Max. output power: 15 dBm
METERLiNK/Bluetooth
Frequency range: 2402–2480 MHz
Antenna Internal
Power system
Battery type Rechargeable Li ion battery
Battery voltage 3.7 V
Battery capacity 4.4 Ah, at +20°C to +25°C (+68°F to +77°F)
Battery operating time Approx. 4 hours at +25°C (+77°F) ambient temper-
ature and typical use
Charging system In camera (AC adapter or 12 V from a vehicle) or 2-
bay charger
Charging time
4 h to 90% capacity, charging status indicated by
LED's
Charging temperature 0°C to +45°C (+32°F to +113°F)
Power management Automatic shutdown and sleep mode (user
selectable)
#T559879; r. AO/35410/35410; en-US
132
