Annotating images19
6. For each row in the table, do the following:
• Push the joystick. This displays the predefined values.
• Move the joystick up/down to select a predefined value. Push the joystick to confirm.
• Instead of selecting a predefined value, you can select the keyboard
and enter
other text.
7. When completed, select Save & Exit at the bottom of the table. Push the joystick to
confirm.
19.4 Adding a voice annotation
19.4.1 General
A voice annotation is an audio recording that is saved to the infrared image file.
The voice annotation is recorded using a Bluetooth headset. The recording can be played
back in the camera, and in image analysis and reporting software from FLIR Systems.
19.4.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
(Add voice annotation) and push the joystick.
4. To start a recording, select
(Record) and push the joystick.
5. To stop the recording, select
(Stop) and push the joystick.
6. To listen to the recording, select
(Play) and push the joystick.
7. To delete the recording, select
(Delete) and push the joystick.
8. When completed, select
(Done) and push the joystick.
19.5 Adding a sketch
19.5.1 General
You can add a freehand drawing to an image.
19.5.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
(Add sketch) and push the joystick.
4. You are now in sketch mode. Draw the sketch by touching the screen.
#T559879; r. AO/35410/35410; en-US
