Camera parts
8
8.4 Battery condition indicator
8.4.1 Figure
8.4.2 Explanation
Type of signal Explanation
The green light flashes. The power supply or the stand-alone battery
charger is charging the battery.
The green light is continuous. The battery is fully charged.
The green light is off. The camera is using the battery (instead of the
power supply).
8.5 Laser pointer
8.5.1 Figure
Figure 8.1 This figure shows the difference in position between the laser pointer and the optical center of
the infrared lens.
WARNING
Do not look directly into the laser beam. The laser beam can cause eye irritation.
Note The laser pointer is enabled by a setting. Select (Settings) > Device settings >
Set up camera > Lamp & laser > Enable lamp & laser.
Note The laser pointer may not be enabled in all markets.
Note The symbol
is displayed on the screen when the laser pointer is on.
#T559879; r. AO/35410/35410; en-US
17
