FLIR T440

Camera parts
8
8.1 View from the rear
8.1.1 Figure
8.1.2 Explanation
1. Touch-screen LCD.
2. Antenna for wireless communication.
3. Digital zoom button.
4. Programmable button.
5. Joystick with push-button functionality.
6. Back button.
7. Camera lamp button.
8. Button to switch between automatic and manual image adjustment mode.
9. Image archive button.
10. On/off button.
11. Hand strap.
8.2 View from the front
8.2.1 Figure
8.2.2 Explanation
1. Laser pointer button. Push to activate the laser pointer.
2. Autofocus/save button.
#T559879; r. AO/35410/35410; en-US
15
