Handling the camera13
3. Align the new eyecup with the eyecup mount on the camera.
4. Carefully slide the eyecup into position.
13.14 Using the camera lamp as a flash
13.14.1 General
The camera lamp can be used as a flash for the digital camera. When the flash function
is activated, the camera lamp will flash when an image is saved by pushing the Autofo-
cus/Save button fully down.
13.14.2 Procedure
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
(Settings).
3. Push the joystick to display the Settings menu.
4. Select Device settings and push the joystick.
5. Select Set up camera and push the joystick.
6. Select Lamp & laser and push the joystick.
7. Select Enable lamp & laser. If the check box is unchecked, push the joystick to ena-
ble the camera lamp.
8. Select Use lamp as flash. If the check box is unchecked, push the joystick to activate
the flash function.
#T559880; r. AK/36075/36075; en-US
33

Table of Contents

Other manuals for FLIR T640

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the FLIR T640 and is the answer not in the manual?

FLIR T640 Specifications

General IconGeneral
Resolution640 x 480 pixels
Temperature Range-40°C to +2000°C
Field of View25° × 19°
Digital Camera5MP
Laser PointerYes
Wi-FiYes
Spatial Resolution (IFOV)0.68 mrad
Image Frequency30 Hz
Accuracy±2°C or ±2% of reading
Video RecordingYes
MeterLinkYes
Operating Temperature-15°C to +50°C
Storage Temperature-40°C to +70°C
ConnectivityUSB, Wi-Fi, Bluetooth
Battery LifeUp to 4 hours
FocusAutomatic or manual
Weight1.3 kg (2.9 lbs)
Spectral Range7.5 - 14 µm
Image StorageSD card
Thermal Sensitivity<30 mK
Lens Options15°, 45°
