STRADA GENERATION3 – S5 - INSTALLATION MANUAL
48/66
7.6 Removing the terminal from the pallet
Install and secure the terminal as soon as it is removed from the pallet.
This operation has to be done with at least 2 persons.
A. Unscrew the 4 M10 screws (1) that secure the terminal to the pallet, being careful not
to tilt the terminal.
Removing the terminal from the pallet
B. Remove the terminal from the pallet.
