STRADA GENERATION3 – S5 - INSTALLATION MANUAL
43/66
7. INSTALLATION OF THE EQUIPMENT
The preparation of a terminal requires:
The lower door key
The standard toolbox.
7.1 Removing the terminal from its transport pallet
Carry the terminal on its pallet to the installation site.
Unpack the terminal.
7.2 Opening the doors with a separate mechanical lock
7.2.1 Preliminary operations
A. Take the mechanical key
7.2.2 Procedure
The mechanical lock is equipped with protective flaps to reduce the risk of vandalism.
A. Insert the tip of the key in the opening of the lock (2).
B. With the tip of the key, push the first protective flap to the left (3) and the second flap
to the right (4).
C. When the lock can be reached, insert the key (1) in the lock (2).
D. Perform a quarter turn with the key to unlock the door.
E. Open the doors.
