STRADA GENERATION3 – S5 - INSTALLATION MANUAL
65/66
• The LED will be turned off when the modem is powered off. If no LED is lit and the
modem is powered on, the SIM is not valid or an incorrect PIN code has been
entered in the terminal configuration.
8.2.2 Blinking pattern
• 10 ms on / 1990 ms off Modem has an active PPP-connection (GPRS and
UMTS) and is ready to communicate.
• 10 ms on / 3990 ms off Modem registered to a network. No call, no data transfer
active.
• 500ms on / 500 ms off Limited Network Service (e.g. because no SIM, no PIN
or during network search)
8.3 Program loading
Usually, a Strada S5 terminal comes complete with the appropriate application Software and
Settings.
The application Software is subject to continuous improvements which means that all
terminals will benefit from being updated now and then.
It may also be necessary to update AVR firmware when the application and Operating
System (OS) have been updated, See the CWT Software Configuration Handbook for
more details.
Finally, it might be that the operating system (Windows EC7) needs to be updated.
8.4 Changing the settings of the terminal
Sometimes, the terminal’s application software settings need to be adapted to meet new
functional requirements. There are some alternative ways to change software parameters.
See the CWT Software Configuration Handbook for more details.
