TECHNICAL CHARACTERISTCS
11
4.35.46.4
12.2
5.2
28.7
HO
CWI
G
HI HWO
1.9 3.1 4 1.2
12.2
28.7
4.47.34.4
1.9 12.3 1.9
4.9
2.7 3.2
2.2 Dimensions
LEGEND
HI
HEATING INLET Ø 3/4 "
HO
HEATING OUTLET Ø 3/4 "
G
GAS Ø 1/2 "
CWI
COLD WATER INLET
Ø 1/2 "
HWO
HOT WATER OUTLET
Ø 1/2 "
SC
CONDENSATE DRAIN Ø 0.98 in
