PARTS LIST
77
6.12 Parts List / Available from FLOWMAX
Main components
20086LA ISOTERMIQUE 5+1 COMBUSTION CHAMBER BACK PANEL
21044LA PRIMARY EXCHANGER 5+1 PREMIX 0.70
24060LA PUMP STAR S 21 KU RSL-PL6 UL/CSA
25-00274 PUMP UPS 15-58 CACAO ETL MOLEX-PN98282128
25-00045 EXPANSION VESSEL 6 lt. – 1,58 gal
25-00274 SAFETY VALVE 3/4"M - 3/4"F 30 psi
30-00015 PLATE EXCHANGER 28 P.
35031LA IGNITION ELECTRODE
35032LA IONISTATION ELECTRODE
36072LA VENTURI MINIFOLD RK50 57KW
36075LA GAS VALVE UL/CSA
37033LA FAN RG 128 / 1300 UL/CSA
59020LA AIR PRESSURE SWITCH 2.14 UL/CSA
73507LA D.H.W-HEATING 1/8" WHITE SENSOR S011001
73516LA HTG CLIP SENSOR FOR PIPE 17/18 mm BLUE-T7335D1123B
73517LA THERMO FUSE 102°C RED ISOTHERM . 1/4" 4X45
76702LA PRINTED CIRCUIT BOARD KOND DT - SK11003
76719LA MAIN PRINTED CIRCUIT BOARD UL/CSA - SM20021
86006LA SAFETY THERMOSTAT 95°C
25-00196 WATER PRESSURE GAUGE
88022LA TRANSFORMER UL/CSA
96018LA NO-RETURN VALVE
96073LA DIVERTER VALVE ACTUATOR UL/CSA
