14.2 Status Code Index
Table 16: Status Code Index
Status Code Name Blink Code
Command Input Below ADC Range RGGG
Command Input Above ADC Range RGGG
Command Input Calibration in Progress GRGY
Command Input Range Too Small RGGG
Digital Command Mode GGYY
Driver Module Alarm RRYR
Factory Reset State RGRR
Feedback Linkage Alarm RRYG
Initializing GGYR
Inner Loop Offset Time Out RGGR
Jog Calibration Set 100% Position GRRR
Jog Command Mode GRRY
Local Interface Off GGYG
Main Board Electronic Failure Warning RYRR
Memory Error Warning YYYR
No Motion Time Out RGYY
Partial Stroke Test Failed Warning YGRR
Piezo Voltage High Alarm RRRY
Piezo Voltage High Warning YRRY
Piezo Voltage Low Alarm RRRY
Piezo Voltage Low Warning YRRY
Pilot Relay Cycles Warning YGGY
Pilot Relay Response Alarm RRGG
Pilot Relay Response Warning YRGG
Pilot Relay Travel Warning YGGY
Position Deviation Alarm RRRR
Position High Limit Alert YGGG
Position Low Limit Alert YGGG
Position Range Too Small RGGY
Position Sensor Above ADC Range RGGY
Position Sensor Below ADC Range RGGY
Position Sensor Failure Alarm RYRG
Power ON GGGG
Setting Inner Loop Offset GRGY
Settle Time Out RGYG
Signature or Partial Stroke Test in Progress GRGG
Soft Stop High Limit Alert GYGY
Soft Stop Low Limit Alert GYGY
Software Error Warning YYRG
Squawk Mode GGRR
Stroke Calibration in Progress GRGY
Stroke Calibration Required RGRG
Stroke Shift RGRY
Stroke Span Decrease RGRY
Stroke Span Increase RGRY
Supply Pressure Low Alarm RYYG
Temperature High Warning YYGG
Temperature Low Warning YYGG
Tight Shut Off Mode GGGY
Valve Can't Open Alarm RYGG
Valve Can't Shut Alarm RYGG
Valve Closed Too Far Warning YYGY
Valve Cycles Warning YGGY
Valve Opened Too Far Warning YYGY
Valve Travel Warning YGGY
