Fluance RT80 - Page 16

Cantilever Carbon Fiber Aluminum
Mount Half inch Half inch
Frequency Response 20-20,000Hz 20-20,000Hz
Channel Separation 18dB at 1kHz 20dB at 1kHz
Channel Balance 2.5dB or less at 1kHz 2.0dB or less at 1kHz
Load Impedance/Capacitance 47k Ohms/100pF 47k Ohms/100pF
Output Voltage 2.5mV +/–3dB 2.5mV +/–3dB
Weight 5.0g 5.7g
Headshell Weight 10g 10g
Recommended Tracking Force 2.0g 2.0g
Vertical Tracking Angle 20 degrees 20 degrees
Output Specications
Connector RCA RCA
Preamp
Yes, PHONO/LINE
Switchable
Yes, PHONO/LINE
Switchable
Phono Output 2.5mV +/–3dB 2.5mV +/–3dB
Line Output 140mV (–17dBV) 140mV (–17dBV)
Ground Terminal Yes Yes
Power Specication
Input
100V - 240V AC
(50/60Hz)
100V - 240V AC
(50/60Hz)
Output 12V / 500mA 12V / 500mA
Consumption 1.5W 1.5W
General Specications
Unit Dimensions ( W x H x D ) 16.5" x 5.5" x 13.75" 16.5" x 5.5" x 13.75"
Unit Weight 4.5 kg (9.9 lb) 6.4 kg (14.41 lb)
Operating Temperature 5°C to 35°C 5°C to 35°C
