8
First Time Setup
Step Four:
Balancing the Tonearm
Important!
Complete all steps for balancing the tonearm. Incorrect tonearm balancing can cause damage to the
stylus and to your records. For additional assistance go to:
www.uance.com/support to watch a tutorial video for this process.
5. With the cueing lever now lowered, turn the entire counterweight until the tonearm
is balanced and floating horizontally when headshell is released.
Tip: When balancing the tonearm make sure the cueing level is down.
1. Remove the stylus protector. 2. Unlock the tonearm and lift the cueing
lever.
Lock Cueing Lever
6. Set only the counterweight indicator ring to “0” on the center line while
keeping the tonearm balanced then lock the tonearm on the tonearm rest.
Counterweight
Indicator Ring
Center Line
3. Position the tonearm over the platter. 4. Hold the headshell and lower the
cueing lever completely. Protect the
stylus from touching the platter.
Cueing Lever
To Next Page
