EXAMPLE
HART Output Communication: Enabled
Poll address: 1
Primary Variable: Total Volume @ Ref. Conditions
Secondary Variable: Volume Flowrate @ Ref. Conditions
Tertiary Variable: Temperature
Quaternary Variable: Pressure
**************** Service port *****************
-------------------------------------------------------------
Slave address: 1
Type: RTU
Baud rate: 38400
Data bits: 8
Parity: None
Stop bits: 2
Register Values: 32 bit floating point (IEEE-754)
**********************************************
************ System Configuration ************
**********************************************
Pipe diameter: 0.3800 m
Transducer distance (M): 0.5370 m
Transducer angle: 45.0 deg
******* Units *******
Velocity: m/s
Volume: m3
Volume flow: m3/h (Cubic meter pr. hour)
Mass: kg
Mass flow: kg/h
Pressure: BarA
Temperature: Celsius
Log time for 24h acc. values: 06:00:00
**********************************************
*********** Input Signal Parameters ***********
**********************************************
Pressure input Current Loop (4-20mA)
Temperature input Current Loop (4-20mA)
Current loop ranges
Temperature, 4mA value: 255.15 [Kelvin]
Temperature, 20mA value: 533.15 [Kelvin]
Pressure, 4mA value: 1.013 [BarA]
Pressure, 20mA value: 12.044 [BarA]
Current loop calibration coefficients
Temperature, offset: 0.0070
