FGM 160 Operating Instructions
72.120.601
Page 16 of 27
EXAMPLE
Temperature, scale: 0.9963
Pressure, offset: 0.0220
Pressure, scale: 0.9980
Alarm limits
Temperature, Hi limit: 533.15 [Kelvin]
Temperature, Lo limit: 255.15 [Kelvin]
Pressure, Hi limit: 12.044 [BarA]
Pressure, Lo limit: 1.013 [BarA]
**********************************************
********** Output signal parameters **********
**********************************************
******** Current loops, 4-20mA ********
Current loop 1, Parameter: Volume Flowrate @ Act. Conditions
Current loop 2, Parameter: Molecular Weight
Current loop 3, Parameter: Testvalue Current Loop 3
Current loop 4, Parameter: Testvalue Current Loop 4
Current loop 5, Parameter: Testvalue Current Loop 5
Current loop 6, Parameter: Testvalue Current Loop 6
Current loop ranges
Current loop 1, 4mA value: 0.00
Current loop 1, 20mA value: 2124000.00
Current loop 2, 4mA value: 0.00
Current loop 2, 20mA value: 50.00
Current loop 3, 4mA value: 4.00
Current loop 3, 20mA value: 20.00
Current loop 4, 4mA value: 4.00
Current loop 4, 20mA value: 20.00
Current loop 5, 4mA value: 4.00
Current loop 5, 20mA value: 20.00
Current loop 6, 4mA value: 4.00
Current loop 6, 20mA value: 20.00
Current loop calibration coefficients
Current loop 1, offset: -0.1217
Current loop 1, scale: 0.9980
Current loop 2, offset: -0.1647
Current loop 2, scale: 1.0045
Current loop 3, offset: -0.1633
Current loop 3, scale: 1.0018
Current loop 4, offset: -0.2105
Current loop 4, scale: 1.0025
Current loop 5, offset: -0.0232
Current loop 5, scale: 1.0078
Current loop 6, offset: -0.1358
Current loop 6, scale: 1.0058
**********************************************
******** Measurement/Signal Parameters *******
**********************************************
