Fluke Biomedical ProSim 2 - Page 20

Vital Signs Simulator
Product Familiarization
7
Table 5 is a list of connectors on the top-panel of the Product shown in Figure 2.
2
1
hal006.eps
Figure 2. Top-Panel Connectors
Table 5. Top-Panel Connectors
Item Name Description
 ECG Posts Connection posts for ECG leads from the patient monitor.
 Mini-Series B Connector For firmware updates and calibration.
