ProSim™ 2/3
Users Manual
30
Table 11. ECG Function Commands (cont.)
Action Command
ST Elevation
[1]
-0.8 mV STD-0.8
-0.7 mV STD-0.7
-0.6 mV STD-0.6
-0.5 mV STD-0.5
-0.4 mV STD-0.4
-0.3 mV STD-0.3
-0.2 mV STD-0.2
-0.1 mV STD-0.1
-0.05 mV STD-0.05
0 mV STD0
+0.05 mV STD+0.05
+0.1 mV STD+0.1
+0.2 mV STD+0.2
+0.3 mV STD+0.3
+0.4 mV STD+0.4
+0.5 mV STD+0.5
+0.6 mV STD+0.6
+0.7 mV STD+0.7
+0.8 mV STD+0.8
Artifact Simulation
[1]
Off EAOFF
50 Hz EA50
60 Hz EA60
Muscle EAMSC
Wandering EAWNDR
Respiration EARESP
1. Set the ECG rate before you set amplitude, ST elevation, and artifact.
Table 12. Pacemaker Waveform Commands
Action Command
Waveforms
Atrial Pacer ATR
Asynchronous pacer ASN
Demand frequent sinus DFS
AV sequential AVS
Noncapture NCA
Nonfunction NFU
