Table 14. ECG Test Commands
Action Command
Performance Waves
2 Hz square wave SQU2
0.125 Hz square wave SQU.125
2 Hz triangle wave TRI2
2.5 Hz triangle wave TRI2.5
30 bpm pulse wave PUL30
60 bpm pulse wave PUL60
0.5 Hz sine wave SIN0.5
5 Hz sine wave SIN5
10 Hz sine wave SIN10
40 Hz sine wave SIN40
50 Hz sine wave SIN50
60 Hz sine wave SIN60
100 Hz sine wave SIN100
Amplitude
0.05 mV PFA0.05
0.10 mV PFA0.10
0.15 mV PFA0.15
0.20 mV PFA0.20
0.25 mV PFA0.25
0.30 mV PFA0.30
0.35 mV PFA0.35
0.40 mV PFA0.40
0.45 mV PFA0.45
0.50 mV PFA0.50
1.00 mV PFA1.00
1.50 mV PFA1.50
2.00 mV PFA2.00
2.50 mV PFA2.50
3.00 mV PFA3.00
3.50 mV PFA3.50
4.00 mV PFA4.00
4.50 mV PFA4.50
5.00 mV PFA5.00
5.50 mV PFA5.50
