Specifications
5
Insulation Resistance
Display Ranges 4.000 MΩ, 40.00 MΩ, 400.0 MΩ, 4000 MΩ
Measurement Range (per EN61557-2) 0.250 MΩ to 4000 MΩ
Resolution 0.001 MΩ to 10 MΩ
2 % + 2 counts
0.250 MΩ to 100.0 MΩ
Accuracy
10 % + 2 counts + 1 %/1000 MΩ
100.0 MΩ to 4000 MΩ
Analog Bar Graph 0 to ∞
Test Voltages 250 V, 500 V, 1000 V
Accuracy +20 %, -0 %
Nominal Current 1 mA
Number of measurements 5,000
Circuitry Protection test inhibited if ≥ 30 V ac or dc at inputs
Lo Ω
Display Range 40.00 Ω
Measurement Range 0.10 Ω to 40.00 Ω
Accuracy 2 % + 2 counts
Resolution 0.01 Ω
Analog Bar Graph 0 to 100 Ω
Open Circuit Voltage 6 V typical
Short Circuit Current 200 mA minimum, (0.2 to 2.0 Ω for >20% battery
capacity remaining).
Test Leads Zero 2 Ω
Number of measurements 5,000
Circuitry Protection test inhibited if • 30 V ac or dc at inputs
Voltage
Range 600 V, dc, 50/60 Hz
Resolution 1 V
Accuracy 2 % + 2 counts
Analog Bar Graph 0 to 1000 V
Resistance
Range 4000 Ω
Accuracy 2 % + 2 counts
Resolution 1 Ω
Analog Bar Graph 0 to 10 kΩ
Beeper On at ≈30 Ω or less

Fluke 1520 Specifications

General

Brand	Fluke
Model	1520
