Fluke 1730 User Manual

1730
Calibration Manual
10
Setup
Before you start the verification procedures or make calibration adjustments,
refer to this section for the equipment, system, and setup requirements.
Required Equipment
See Table 3 for a list of requirements for the verification tests and calibration
adjustment of the 1730.
Table 3. Required Equipment
Equipment Model Notes
Used on:
Verification
Tests
Calibration
Adjustment
Calibrator 5522A
5520A is also
supported
X X
Coil 5500A/COIL
X X
Cable Assembly 3PHVL-1730
Voltage Test
Lead 3-Phase+N
X X
1730 AUX Input Cable PN 4395217 Qty. 2 required
X X
Male BNC to Dual
Female BNC Adapter
PM9093
X X
BNC Female to Double
Banana Plug
Pomona 1269
X X
1730 Calibration
Cables – Voltage-to-
Current Input Cable
Assembly
[1]
NA Qty. 3 required
X X
1730 Verification Box
[1]
NA optional
X
USB cable
type A-to-mini
A
X X
[1] The 1730 calibration cables and verification box are not available from Fluke. See Equipment Assembly for
information on how to make these items.
Equipment Assembly
The 1730 calibration cables and verification box are not available from Fluke. If
you plan to calibrate your Product rather than send it to a Fluke Service Center,
use the assembly instructions that follow.
