Setup
13
System Requirements
The system requirements for this verification procedure are:
• WinXP 32-bit, Windows 7 32/64-bit, Windows 8 32/64-bit
• Monitor, 1280 x 1024 (@4:3) or 1440 x 900 (@16:10), wide-screen (16:10) at
higher resolution recommended
• USB 2.0 port
• RS232 port to control the calibrator (optional)
• Microsoft Excel 2010 32-bit software or higher (versions below 2010 not
tested)
• Fluke Energy Analyze software
USB Communication
Some of the range changes in the verification require remote commands to set
the range. To communicate between the PC and the 1730, the 1730 driver must
be installed. This driver is installed when the Fluke Energy Analyze (FEA)
software is installed.
Use these steps to identify the COM port:
1. Make sure the instrument is powered and connected with the PC.
2. Press: <Windows key>-R.
3. Type: devmgmt.msc <ENTER>.
4. Go to Ports (COM & LPT) and double-click to open the sub-tree.
5. Find Fluke 1730 Energy Logger. The port number is shown in parenthesis
after this text, for example, COM6.
A detailed description of the spreadsheet is found in the How to Use the
Spreadsheet section.

Fluke 1730 Specifications

General

Power Quality	Yes
Data Logging	Yes
Display	Color LCD
Enclosure	IP50
Safety Rating	CAT IV 600 V / CAT III 1000 V
Weight	1.1 kg
Current Measurement Range	Depending on probe: 0.5 A to 6000 A
Power Quality Parameters	Harmonics, Flicker, Unbalance
Power Accuracy	± 0.5 %
Communication Interface	USB, Ethernet
Operating Temperature	-10°C to +50°C
Dimensions	198 mm x 167 mm x 59 mm
