Fluke 1750 Calibration Manual

Power Recorder
Required Equipment
7
The cables listed in Table 3 are necessary for verification and calibration adjustment. To
assemble the cables, see cable assembly figures in the Test Cables section.
Table 3. Required Cables
Cable Required Characteristics Notes
Ethernet cable CAT 5 with RJ-45 connectors Supplied with the Recorder
Voltage calibration cable
with BNC-banana adapter
Double banana to safety banana
and spade lug
See Figure 5
Four jumper cables, safety-
banana type
Current calibration cable
Shielded cable with double banana
to CT pins in Redel connector with
100 A CT ID resistor
See Figure 6
Rogowski resistor
measurement cable
Safety banana to Redel See Figure 4
Rogowski calibration cable
Shielded cable with double banana
to Rogowski pins in Redel connector
with 100 A Rogowski ID resistor
See Figure 3
Ground calibration cable Lug to banana See Figure 2
Fluke recommends the use of Pomona brand cables and banana plugs when building these cables.
