1760
Users Manual
6-22
Current: Nominal value In, sinusoidal waveform, 48 –
65 Hz
Distortion factor: < 1 %. No DC stray field <40 A/m, conductor
centered within the Flexi current sensor
Safety Standards
• IEC/EN 61010-1 2
nd
edition
• IEC/EN 61010-2-032
• IEC/EN 61010-2-031
EMC Standards
EN61326 –1:2006
XW Warning
To protect against electrical shock:
• Utilize the clamps only on insulated conductors, max.
600 V rms or dc to ground.
• Use personal protective equipment measures as required
by local government agencies, when attaching clamps to
live circuits.
Accuracy (Typical, for 50/60 Hz)
Linearity, error in % of measured value, primary current in A:
