1760
Users Manual
6-6
Shunt Resistors for AC and DC Currents
Model No.
Product No.
Type Range
Peak
Current
for
Sinusoidal
Currents
Intrinsic
Uncertainty
(>1 % of
range)
Frequency
Range
Operating
Voltage
Phase
Error
TPS SHUNT
20 MA
PN 2540553
SHUNT
20 mA
0 – 55 mA 77.8 mA
Imax=1.5 A
0.2 % DC 3.0 kHz 300 V CAT II 0.1 °
TPS SHUNT
1 A
PN 2540548
SHUNT
1 A
0 – 2.8 A 4 A
Imax=5.5 A
0.2 % DC 3.0 kHz 300 V CAT II 0.1 °
TPS SHUNT
5 A
PN 2540566
SHUNT
5 A
0 – 10 A 21.9 A
Imax=10 A
0.2 % DC 3.0 kHz 300 V CAT II 0.1 °
Errors in % of measuring range at 23 °C ± 2 K, for 48 – 65 Hz.
Phase angle error at nominal current.
I
max
maximum current without time limit.
Other Accessories
Product Description/technical specifications Product- No.
Transport case For Instrument and accessories 2540414
Safety adapter With quick-break fuse of 100 kA circuit-breaking capacity 2540530
2 A quick-break fuse With 100 kA circuit-breaking capacity 2540509
Battery pack Replacement battery pack 2540406
Current Clamp 1 A/10 A AC
This current probe has been designed for non intrusive, accurate measurements of small
AC currents. Using latest technologies (internal memory for calibration data) provides
current ranges from 0.01 A up to 10 A. The measurement range can be selected in the PQ
Analyze software: IAC1 or IAC10.
XW Warning
To protect against electrical shock:
• Use personal protective equipment measures as required
by local government agencies, when attaching clamps to
live circuits.
• Utilize the clamps only on insulated conductors, max.
600 V r.m.s. or dc to ground.
