1760
Users Manual
1-8
XW
Warning
Risk of voltage peaks in higher categories. Connect the supply
cable of the device only to sections CAT I, II or III of the supply
system (Refer to the ‘Functional Description’ section) the
voltage to earth may not exceed 300 V.
Input Voltage – Measuring Inputs
The measurement category (refer to Functional Description section) and the max. voltage
to earth of the sensors has to conform to the power supply system (See the inscription and
the technical specifications of the accessories).
Servicing and Maintenance
• Do not remove the cover
• Refer servicing to qualified personnel
• The user can replace the accumulator package (Refer to Chapter 4, Maintenance)
Design and Functions
This section provides an overview of the terminals, ports and interfaces of the Recorder,
as well as a list of displays and operating devices and a brief introduction to the basic
functions of the unit.
Mains Connection and Interfaces
Figure 1-3 and Figure 1-4 show the top view and front view of the Recorder respectively.
11
grafikview.eps
Figure 1-3. Top View
To Next Page
