Fluke 1760 - Page 50

1760
Users Manual
3-10
Fluke 1760
PEN
L1
L2
L3
L1
L2
L3
N
PE
Load
Transformer
3wattm2.eps
Figure 3-5. Circuit Diagram: 4-Wire
Associated PC Software Settings:
messsystem1 u-i-0.bmp
If required, you have the option to determine events, Flicker and Harmonics, of the
phase-to-phase voltages.
Check the respective option.
messsystem1 u-i-2.bmp
