Fluke 177 Calibration Information

175, 177, & 179
Calibration Information
10
Performance Tests
WWarning
To avoid electric shock, do not perform the performance test procedures unless
the Meter is fully assembled.
The following performance tests verify the complete operation of the Meter and check the accuracy of
each meter function against the Meter’s specifications. If the Meter fails any part of the test, calibration
adjustment and/or repair is indicated.
In the performance tests, the Meter is referred to as the unit under test (UUT).
Required Equipment
A Fluke 5500A Multi-Product Calibrator (or equivalent) is required for the performance test procedures
in this document.
If an equivalent calibrator is used, it must meet the accuracy specifications shown in Table 1.
Table 1. Calibrator Specifications
Recommended Equipment Measurement Function Accuracy
5500A Multi-Product Calibrator
(or equivalent)
DC Volts 0 to 1000 V
± 0.075 %
DC Current 0 to 10 A
± 0.425 %
AC Volts 0 to 1000 V
± 0.375 % @ 45 Hz to 1 kHz
AC Current 0 to 10 A
± 0.55 %
Resistance 0 to 4 MΩ
± 0.125 %
4 to 40 MΩ
± 0.5 %
Capacitance 500 pF to 5 µF
± 0.325 %
Temperature .25%
Frequency 0.5 Hz to 100 kHz
± 0.005 %
Fluke 80 AK
Thermocouple Adapter Accessory
K-type -
K-type Thermocouple K-type, mini-plug on both ends -

Fluke 177 Specifications

General

Frequency range	0.00001 - 100 kHz
DC current range	0.00001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	10 µA
Resolution (DC voltage)	0.1 mV
Basic accuracy (frequency)	±(0.1% + 1)
Basic accuracy (DC voltage)	±(0.09% + 2)
Basic accuracy (resistance)	±(0.9% + 1)
Basic accuracy (capacitance)	±(1.2% + 2)
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1
Manual	Yes

Weight and Dimensions

Depth	43 mm
Width	90 mm
Height	185 mm
Weight	420 g
