Fluke 177 Calibration Information

True RMS Multimeters
Calibration
15
6. When the last step in a function is reached, turn the knob to the next function required. The Meter will
not allow a step to be completed if the knob is turned to the wrong function.
Note
If the calibration procedure is not completed correctly, the Meter will not operate correctly. When
calibration is not performed correctly, the Meter displays the messages “CaL” and “Err”and the
Meter must be recalibrated.
The meter is damaged and requires service if:
• “CaL” and “Err” messages continue to appear after a proper recalibration.
• “EEPr” and “Err”messages are alternating on the display.
• “EEPr” message appears on the display.
Calibration seal
Calibration button
aik14f.eps
Figure 4. Calibration Access

Fluke 177 Specifications

General

Frequency range	0.00001 - 100 kHz
DC current range	0.00001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	10 µA
Resolution (DC voltage)	0.1 mV
Basic accuracy (frequency)	±(0.1% + 1)
Basic accuracy (DC voltage)	±(0.09% + 2)
Basic accuracy (resistance)	±(0.9% + 1)
Basic accuracy (capacitance)	±(1.2% + 2)
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1
Manual	Yes

Weight and Dimensions

Depth	43 mm
Width	90 mm
Height	185 mm
Weight	420 g
