Fluke 177 User Manual

175, 177, 179
Users Manual
12
XW Warning
To avoid electric shock, fire, or personal injury:
• Connect the common test lead before the live test
lead and remove the live test lead before the
common test lead.
• Disconnect power and discharge all high-voltage
capacitors before you measure resistance,
continuity, capacitance, or a diode junction.
Measure AC and DC Voltage
_
+
_
+
Volts AC
Volts DC
Millivolts DC
V
V
mV
RANGEHOLD
MIN MAX
RANGEHOLD
MIN MAX
RANGEHOLD
MIN MAX
AIK03F.EPS
Measure Resistance
RANGEHOLD
MIN MAX
AIK04F.EPS
Measure Capacitance
+
_
+
RANGEHOLD
MIN MAX
AIK05F.EPS

Fluke 177 Specifications

General

Frequency range	0.00001 - 100 kHz
DC current range	0.00001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	10 µA
Resolution (DC voltage)	0.1 mV
Basic accuracy (frequency)	±(0.1% + 1)
Basic accuracy (DC voltage)	±(0.09% + 2)
Basic accuracy (resistance)	±(0.9% + 1)
Basic accuracy (capacitance)	±(1.2% + 2)
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1
Manual	Yes

Weight and Dimensions

Depth	43 mm
Width	90 mm
Height	185 mm
Weight	420 g
