Fluke 177 User Manual

True-rms Multimeters
Symbols
3
• The battery door must be closed and locked before
you operate the Product.
• Use only cables with correct voltage ratings.
• Remove all probes, test leads, and accessories
before the battery door is opened.
• Replace the batteries when the low battery indicator
shows to prevent incorrect measurements.
• Do not apply more than the rated voltage, between
the terminals or between each terminal and earth
ground.
• Measure a known voltage first to make sure that the
Product operates correctly.
• Use the correct terminals, function, and range for
measurements.
• Do not use test leads if they are damaged. Examine
the test leads for damaged insulation, exposed metal,
or if the wear indicator shows. Check test lead
continuity.
• Do not touch the probes to a voltage source when
the test leads are connected to the current terminals.
• Do not use test leads if they are damaged. Examine
the test leads for damaged insulation and measure a
known voltage.
• Do not use in CAT III or CAT IV environments without
the protective cap installed on test probe. The
protective cap decreases the exposed probe metal to
<4 mm. This decreases the possibility of arc flash
from short circuits.
Symbols
Table 1 is a list of the symbols used on the Product and in this
manual.
Table 1. Symbols
Symbol Description
 Consult user documentation.
W WARNING. RISK OF DANGER.
X
WARNING. HAZARDOUS VOLTAGE. Risk of
electric shock.
 Earth

AC (Alternating Current)

DC (Direct Current)

Both direct and alternating current

Fluke 177 Specifications

General

Frequency range	0.00001 - 100 kHz
DC current range	0.00001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Resistance resolution	0.1 Ω
Resolution (frequency)	0.01 Hz
Resolution (AC current)	10 µA
Resolution (DC voltage)	0.1 mV
Basic accuracy (frequency)	±(0.1% + 1)
Basic accuracy (DC voltage)	±(0.09% + 2)
Basic accuracy (resistance)	±(0.9% + 1)
Basic accuracy (capacitance)	±(1.2% + 2)
Battery type	9V
Battery voltage	9 V
Number of batteries supported	1
Manual	Yes

Weight and Dimensions

Depth	43 mm
Width	90 mm
Height	185 mm
Weight	420 g
