27 II/28 II
Calibration Information
12
Required Equipment
Table 2 lists the equipment required to conduct a performance test on the Meter.
Table 2. Required Equipment
Recommended Equipment Measurement Function Accuracy
DC Volts 0 to 1000 V
±0.012 %
DC Current 350 μA to 2 A
±0.05 %
AC Volts 0 to 1000 V
±0.15 % @ 60 Hz to 20 kHz ±3 %
AC Current 350 μA to 2 A
±0.39 % @ 60 Hz to 1 kHz
Resistance 1 Ω to 100 MΩ
±0.06 %
Capacitance 9 to 900 μF
±0.475 %
5520A Multi-product Calibrator
(or equivalent)
Frequency 19.999 to 199.99 kHz, ±0.0137 %
150 mV to 6 Vrms, ±5 %
K-type Thermocouple, mini-plug
on both ends
Temperature
