27
Service Manual
1-6
Table 1-1. Specifications (cont)
Function Overload
Protection**
Input Impedance
(nominal)
Common Mode Rejection
Ratio
(1 kJ unbalance)
Normal Mode
Rejection
F 1000 V rms 10 M
J
in // with <100pF >120 dB at dc, 50 Hz, or 60 Hz >60 dB at 50 Hz or 60 Hz
l 1000 V rms 10 M
J
in // with <100pF >120 dB at dc, 50 Hz, or 60 Hz >60 dB at 50 Hz or 60 Hz
G 1000 V rms
10 M
J
in // with <100pF
(ac coupled)
>60 dB, dc to 60 Hz
I 1000 V rms
10 M
J
in // with <100pF
(ac coupled)
>60 dB, dc to 60 Hz
J 1000 V rms Open Circuit Test
Voltage
Full Scale Voltage
Up to 3.2 MJ 32 MJ or nS
<2.8 V dc <420 mV dc <1.3 V dc
** 10
7
V Hz Max
Basic electrical accuracy is specified from 18°C to 28°C with relative humidity up to 95%, for a period of one year after
calibration. All ac conversions are ac coupled, average responding, and calibrated to read the true rms value of a sine wave
input. Accuracy is specified as ±([% of reading] + [number of least significant digits]).
Ranging is either automatic or manual in all functions with more than one range. Test resistance below approximately 270
J
in the
RG
function produces a continuous audible tone.
Maximum voltage between any
terminal and earth ground
1000 V
Fuse protection
mA or µA
A
44/100 A 1000 V Fast
11 A 1000 V Fast
Digital Display 3200 counts, updates 2/sec
Analog Display 31 segments, updates 25/sec
Operating Temperature -15°C to 55°C, to -40°C for 20 minutes when taken from 20°C
Storage Temperature -55°C to 85°C without battery, to 60°C with battery
Electromagnetic Compatibility
In an RF field of 2 V/m on all ranges and functions (except mVac),
total accuracy = specified accuracy + 1.0% or range. For mVac,
total accuracy = specified accuracy + 1.5% or range. EN 61326-1:1997.
Temperature Coefficient 0.1 x (specified accuracy)/°C (18°C or >28°C)
Relative Humidity 0% to 95% (0°C to 35°C)
0% to 70% (35°C to 55°C)
Altitude 2000 meters
Battery Type 9 V, NEDA 1604 or 6F22 or 006P
Battery Life 1000 hrs typical
Shock, Vibration and Water
Resistance
Per MIL-T-28800 for a Style A, Class 2 Instrument
Size (HxWxL) 2.2 in x 3.75 in x 8 in (5.6 cm x 9.5 cm x 20.3 cm)
Weight 1.6 pounds (0.75 kg)
Waterproof 1 meter
Safety Complies with ANSI/ISA S82.01-1994, CAN/CSA 22.2 NO. 1010.1:1992 to
1000 V Overvoltage Category III. UL License pending to UL3111-1. TUV
License pending to EN61010-1.
