Fluke 28 II Ex Calibration Information

28 II Ex
Calibration Information
4
Electrical Symbols
Table 1 is a list of electrical symbols that appear in this document and on the Meter.
Table 1. Symbols
W
WARNING - RISK OF DANGER. Consult user documentation.
X
WARNING. HAZARDOUS VOLTAGE. Risk of electric shock.
T
Double Insulated

AC (Alternating Current)

DC (Direct Current)

Earth

Fuse

Battery. Low battery when displayed.
R
Continuity test or continuity beeper tone.

Capacitance
O
Diode
P
Conforms to European Union directives.

Conforms to relevant South Korean EMC Standards.
(
Conforms to the European Explosive Atmospheres (ATEX) directive.
)
Certified by CSA Group to North American safety standards.

Certified by TÜV SÜD Product Service.

Conforms to relevant Australian Safety and EMC standards.

Measurement Category II is applicable to test and measuring circuits connected directly to utilization
points (socket outlets and similar points) of the low-voltage MAINS installation.

Measurement Category III is applicable to test and measuring circuits connected to the distribution part of
the building’s low-voltage MAINS installation.

Measurement Category IV is applicable to test and measuring circuits connected at the source of the
building’s low-voltage MAINS installation.
~
This product complies with the WEEE Directive marking requirements. The affixed label indicates that
you must not discard this electrical/electronic product in domestic household waste. Product Category:
With reference to the equipment types in the WEEE Directive Annex I, this product is classed as
category 9 "Monitoring and Control Instrumentation" product. Do not dispose of this product as unsorted
municipal waste.

Fluke 28 II Ex Specifications

General

Diode test	Yes
Product type	Digital multimeter
Product color	Black, Red
Frequency range	0.0005 - 199.99 kHz
DC current range	0.0000001 - 10 A
DC voltage range	0.0001 - 1000 V
Resistance range	0.1 - 50000000 Ω
Measuring category	CAT IV 600V
Placement supported	Handheld multimeter
Basic accuracy (frequency)	0.005%
Basic accuracy (DC current)	0.2%
Basic accuracy (DC voltage)	0.05%
Temperature measurement range	-200 - 1090 °C
Battery type	AAA
Power source	Battery
Battery technology	Alkaline
Number of batteries supported	3
Operating altitude	0 - 2000 m
Maximum storage altitude	10000 m
Operating relative humidity (H-H)	0 - 80 %

Weight and Dimensions

Depth	198.1 mm
Width	100 mm
Height	6.35 mm
Weight	698.5 g
