Fluke 289 - Hazardous Voltage

True-rms Digital Multimeters
General Specifications
5
General Specifications
Maximum voltage between any Terminal and Earth Ground: 1000 V
W Fuse Protection for mA or μA inputs............. 0.44 A (44/100 A, 440 mA), 1000 V FAST Fuse, Fluke specified part
only
W Fuse Protection for A input ............................ 11 A, 1000 V FAST Fuse, Fluke specified part only
Battery Type .......................................................... 6 AA Alkaline batteries, NEDA 15A IEC LR6
Battery Life ............................................................ 100 hours minimum. 200 hours in Logging mode
Temperature
Operating ............................................................ -20 °C to 55 °C
Storage ............................................................... -40 °C to 60 °C
Relative Humidity.................................................. 0 % to 90 % (0 °C to 37 °C), 0 % to 65 % (37 °C to 45 °C), 0 % to 45 %
(45 °C to 55°C)
Altitude
Operating ............................................................ 3,000 m
Storage ............................................................... 10,000 m
Temperature Coefficient....................................... 0.05 X (specified accuracy) /°C (<18 °C or >28 °C)
Vibration ................................................................ Random Vibration per MIL-PRF-28800F Class 2
Shock ..................................................................... 1 meter drop per IEC/EN 61010-1 2
nd
Edition
Size (HxWxL) ......................................................... 8.75 in x 4.03 in x 2.38 in (22.2 cm x 10.2 cm x 6.0 cm)
Weight .................................................................... 28.0 oz (871 g)
Safety Standards
US ANSI.............................................................. Complies with ANSI/ISA 82.02.01 (61010-1) 2004
CSA..................................................................... CAN/CSA-C22.2 No 61010-1-04 to 1000 V Measurement Category III
and 600 V Measurement Category IV, Pollution Degree 2
UL ....................................................................... UL 61010 (2003)
CE European ...................................................... IEC/EN 61010-1 2
nd
Edition Pollution Degree 2
Electromagnetic Compatibility Standards (EMC)
European EMC ................................................... EN61326-1
Australian EMC................................................... ; N10140
US FCC............................................................... FCC CFR47: Part 15 CLASS A
Certifications ......................................................... UL, CE, CSA, ; (N10140),
s
Detailed Specifications
Accuracy:
Accuracy is specified for a period of one year after calibration, at 18 °C to 28 °C (64 °F to 82 °F), with relative humidity to
90 %. Accuracy specifications are given as: ±( [ % of reading ] + [ number of least significant digits ] ). Accuracy
specification assumes ambient temperature stable at ±1 °C. For ambient temperature changes of ±5 °C, rated accuracy
applies after 2 hours. To obtain full accuracy in DC mV, Temperature, Ohms and Lo (50) Ohms, let the meter stabilize 20
minutes after using LoZ.
True-rms:
AC mV, AC V, AC μA, AC mA, and AC A specifications are ac-coupled, true rms, and are specified from 2 % of range to
100 % of range, except 10 A range is specified from 10 % to 100 % of range.
Crest Factor:
Accuracy is specified with AC crest factor ≤ 3.0 at full-scale, increasing linearly to 5.0 at half-scale, except the 1000 V
range, where it is 1.5 at full scale, increasing linearly to 3.0 at half-scale and 500 mV and 5000 μA, where it is ≤3.0 at 80
% of full scale, increasing linearly to 5.0 at half-scale. For non-sinusoidal waveforms add ±(0.3 % of range and 0.1 % of
reading).
AC Floor:
When the input leads are shorted together in the ac functions, the Meter may display a residual reading up to 200 counts.
A 200 count residual reading will cause only a 20 count change for readings at 2 % of range. Using REL to offset this
reading may produce a much larger constant error in later measurements.
AC+DC:
AC+DC is defined as
22
dcac +
