Fluke 289 Calibration Manual

True-rms Digital Multimeters
Parts
27
Parts
Table 8 lists that available replacement parts shown in Figure 5.
Table 8. Replacement Parts
Ref
Des.
Description Fluke Part No.
MP1 FLUKE-28X-4001,PCA MAIN Not available
MP2
FLUKE-287-2004-01,SKIN, PADXFER
2798418 (289)
2798429 (287)
MP3 FLUKE-28X-2001,CASE TOP 2578178
MP4 FLUKE-28X-2002,CASE BOTTOM 2578184
MP5
FLUKE-28X-2501,MASK, LCD, PADXFER
2760673 (289)
2798407 (287)
MP6 FLUKE-28X-2006,SHIELD, UPPER 2578252
MP7 FLUKE-28X-2008-01,KNOB, PADXFER 2798434
MP8 FLUKE-28X-2009,HOUSING, RSOB, UPPER 2578283
MP9 FLUKE-28X-2010,HOUSING, RSOB, LOWER 2578290
MP12 FLUKE-28X-2015,SPRING DETENT 2723772
MP16 FLUKE-28X-8002,KEYPAD 2578234
F1 FUSE, .440A,1000V,FAST,.406X1.375,BULK 943121
F2 FUSE,11A,1000V,FAST.406INX1.5IN,BULK 803293
XBT1 FLUKE-28X-8006,BATTERY CONTACT, POSITIVE, BOTTOM CASE 2578353
XBT2-3 FLUKE-28X-8007,BATTERY CONTACT,NEGATIVE,BOTTOM CASE 2578375
DS1
LCD MODULE,289,320X240,FSTN,3.5 MONO
GRAPHIC,TRANSFLCTV,WHITE LED,0.22MM PITCH
2734828
H15-18 SCREW,M3X0.5,6MM,PAN,PHILLIPS,STEEL,ZINC-CHROMATE 2743764
H7-14
SCREW,4-14,.510,PAN,PHILLIPS,STEEL,ZINC-CHROMATE,TYPE BT
THREAD CUT
853668
H1-6
BATTERY,PRIMARY,MNO2-
ZN,1.5V,2.24AH,15A,LR6,ALKALINE,AA,14X50MM,BULK
376756
MP30 O-RING,NITRILE,SHORE A 90,AS 568A-905,.414 ID,.072 W 2740185
MP42-44 FLUKE-28X-8013,SHOCK ABSORBER, LCD 2793516
MP49 FLUKE-28X-2007,SHIELD, LOWER 2578265
MP45 FLUKE-28X-8014,SHOCK ABSORBER, BATTERY COMPARTMENT 2793525
MP46 FLUKE-28X-2019,BATTERY DOOR ASSEMBLY 2824477
