345
Calibration Manual
18
State Key Action Comments
V4 H Screen for V4:
“VOLTS COMMON MODE”
“V CM” – hex value
On completion:
“Press <RUN> when ready”
Next State: V5
V5 H Screen for V5:
“VOLTS 4V CAL”
“APPLY 4V DC”
“Press <RUN> when ready”
Next State: V6
V6 H Screen for V6:
“VOLTS 4V CAL”
“V to ASIC V” – Cal value
“V to ASIC A” – Cal value
“V SCF”
Cal Value – hex value
“A SCF”
Cal value- hex value
On completion:
“Press <RUN> when ready”
Next State: V7
V7 H Screen for V7:
“VOLTS 40V CAL”
“APPLY 40V DC”
“Press <RUN> when ready”
Next State: V8
V8 H Screen for V8:
“VOLTS 40V CAL”
“V to ASIC V” – Cal value
“V to ASIC A” – Cal value
On completion:
“Press <RUN> when ready”
Next State: V9
V9 H Screen for V9:
“VOLTS 400V CAL”
“APPLY 400V DC”
“Press <RUN> when ready”
Next State: V10
