Power Quality Clamp Meter
Calibration Adjustment
19
State Key Action Comments
V10 H Screen for V10:
“VOLTS 400V CAL”
“V to ASIC V” – Cal value
“V to ASIC A” – Cal value
On completion:
“Press <RUN> when ready”
Next State: V11
V11 H Screen for V11:
“SAVING VOLTS CAL”
On completion:
“Press <RUN> when ready”
Next State: S6
A1 HOLD Screen for A1:
“HALL OFFSETS”
“Apply 0A”
“Press <RUN> when ready”
Next State: A2
A2 H Screen for A2:
“HALL OFFSETS”
“A to ASIC A, 40A” – hex value
“TOP HALL” – hex value
“BOTTOM HALL” – hex value
On completion:
“Press <RUN> when ready”
Next State: A3
A3 H Screen for A3:
“SENSITIVITY TEST”
“APPLY 40A DC”
“TO TOP OF JAWS”
“Press <RUN> when ready”
Next State: A4
The arrow at the top of the
case shows the current flow
direction.
A4 H Screen for A4:
“SENSITIVITY TEST”
“TOP HALL” – ASIC reading –
hex
“BOTTOM HALL” – ASIC reading
- hex
On completion:
“Press <RUN> when ready”
Next State: A5
