345
Calibration Manual
20
State Key Action Comments
A5 H Screen for A5:
“SENSITIVITY TEST”
“APPLY 40A DC”
“TO BOTTOM OF JAWS”
“Press <RUN> when ready”
Next State: A6
A6 H Screen for A6:
“SENSITIVITY TEST”
“TOP HALL” – ASIC reading –
hex
“BOTTOM HALL” – ASIC reading
– hex
“Gain Adjustment” – ASIC reading
- hex
On completion:
“Press <RUN> when ready”
Next State: A7
“Gain Adjustment” – ASIC
reading
A7 H Screen for A7:
“AMPS BALANCE”
“APPLY 40A 60Hz
“TO TOP OF JAWS”
“Press <RUN> when ready”
Next State: A8
A8 H Screen for A8:
“AMPS BALANCE”
“BALANCE” – hex value
On completion:
“APPLY 40A 60Hz
“TO BOTTOM OF JAWS”
“Press <RUN> when ready”
Next State: A9
A9 H Screen for A9:
“AMPS BALANCE”
“BALANCE” – hex value
On completion:
if Count < 7:
“APPLY 40A 60Hz
“TO TOP OF JAWS”
“Press <RUN> when ready”
Next State: A8
if Count = 7:
“DONE <RUN>”
Next State: A10
