Power Quality Clamp Meter
Calibration Adjustment
21
State Key Action Comments
A10 H Screen for A10:
“AMPS ZEROING”
“APPLY 0A”
“Press <RUN> when ready”
Next State: A11
A11 H Screen for A11:
“AMPS ZEROING”
“A to ASIC A, 40A” – hex value
On completion:
“Press <RUN> when ready”
Next State: A12
A12 H Screen for A12:
“AMPS GAIN”
“APPLY 40A DC”
“Press <RUN> when ready”
Next State: A13
A13 H Screen for A13:
“AMPS GAIN”
“GAIN POT” – hex value
“Press <RUN> when ready”
Next State: A14
A14 H Screen for A14:
“AMPS OFFSETS”
“APPLY 0A”
“Press <RUN> when ready”
Next State: A15
A15 H Screen for A15:
“AMPS OFFSETS”
“A to ASIC A, 40A” – hex value
“A to ASIC V, 40A” – hex value
“A to ASIC A, 400A” – hex value
“A to ASIC V, 400A” – hex value
“A to ASIC A, 2000A” – hex value
“A to ASIC V, 2000A” – hex value
“V to A difference – hex value
On completion:
“Press <RUN> when ready”
Next State: A16
