Fluke 345 - Page 31

Power Quality Clamp Meter
Calibration Adjustment
23
State Key Action Comments
C1 E Screen for C1:
Screen showing colours and writing.
Right arrow to increase, left arrow to
decrease, contrast. Up arrow to
toggle backlight.
“Press <RUN> when ready” to save.
Next State: S6
T1
Self
Test
M Screen for T1:
Symbols of the 8 keys.
“Press RUN twice for next test”
Next State: T2
As each key is pressed,
and indication appears on
the screen. Since the RUN
key is also checked, it must
be pressed for a second
time.
T2 H Screen for T2:
“EEPROM TEST”
“Press <RUN> when ready”
On completion:
“PASS” or “FAIL”.
“Press <RUN> in Screen tests”
Next State: T3
Simple, not exhaustive,
tests only. After each test is
run, a PASS/FAIL message
is displayed.
T3 H Black screen.
Next State: T4
Tests that all pixels can be
turned off. Press <RUN> as
each screen appears to go
to the next test.
T4 H Red screen.
Next State: T5
T5 H Green screen.
Next State: T6
T6 H Blue screen.
Next State: S6
D1 F Screen for D1: date & time as in
menu.
Next State: S6
F1 G Screen for X1:
“SAVED SCREENS AND
LOGGING SESSIONS CLEARED”
“Press <RUN> when ready”
Next State: First Calibration Screen
Calibration is now complete.
