Specifications
Electrical Measurements23
23-3
DISPLAY MODES
Waveform display Available in Scope and Transient mode
Captures 8 waveforms simultaneously
Display update rate 5x per second
Up to 10/12 times horizontal zoom
Cursors: Single vertical line showing min, max, avg reading at cursor position.
Phasor Shows real time phasor diagram
Available in Scope and Unbalance mode
Display update rate 5x per second
Meter readings Available in Volts/Amps/Hertz, Harmonics, Power & Energy, Flicker, Unbalance
and Logger4 mode.
AutoTrend graph Available in Volts/Amps/Hertz, Dips & Swells, Harmonics, Power & Energy,
Flicker, Unbalance, Inrush, Mains Signaling
4
Logger
4
and Monitor mode
Cursors: single vertical line showing with min, max, avg reading at cursor
position.
Bargraph Available in Harmonics and Monitor mode
Eventlist Available in Dips & Swells Mains Signaling
4
, Logger
4
and Monitor mode
