Display Information
Introduction
The Analyzer uses five different screen types to present measuring results in the most
effective way. The features these screens have in common are explained in this chapter.
Details that are specific for a certain measuring mode are presented in the chapter
explaining that mode. The screen header is presented in the selected information
language. The figure below gives an overview of the screen types 1 .. 5; common features
are explained under A ... F.
2
C
D
E
F1
F2 F3 F4 F5
F
3
44
5
A
1
B
Figure 5-1. Survey of Display Types
