Logger
Events17
17-7
In Normal mode major event characteristics are listed: start time, duration, and voltage
magnitude. Detail shows details of threshold crossings per phase.
The following Abbreviations and Symbols are used in the tables:
Abbreviation Description Symbol Description
CHG Rapid Voltage Change Rising voltage edge
DIP Voltage Dip Falling voltage edge
INT Voltage Interruption
Change upwards
SWL Voltage Swell
Change downwards
Available function keys:
F3
Switch between NORMAL and DETAILED event table.
F4
Return to Meter screen.
F5
Return to Trend screen.
