5730A
Calibration Manual
48
Table 3. List of Required Equipment for Main Output
Determine Specification Limits for other Calibration Intervals
The verification procedures in this document test to the 90 day 99 % confidence
specification limits. For other calibration intervals, it is necessary to calculate
limits based upon the specification that was selected. The subsequent examples
show how the 90 day specification limits were calculated. These examples
illustrate how to calculate the specifications limits for other intervals or levels of
confidence.
The next example shows how to calculate a specification limit for a particular test
point from the combined specification which is listed as a percentage (or parts
per million) of reading plus a floor error in microvolts, millivolts, microamps or
nanoamps. The component of the specification in parts per million is referred to
as a range specification. The floor specification has the same base units of
measurement as the output value (volts, amps). It is not appropriate to add a
range specification and floor specification together directly, because they are not
in the same units of measurement. In order to add the two quantities, it is
Equipment Description Application
AC Measurement Standard or Fluke 5790A ACV, ACI
Resistance Standards Fluke 742A Series Cal, Ohms, DCI
Reference Divider Fluke 752A DCV
Null Detector Fluke 8508A DCV
DC Reference Standard Fluke 732B DCV
Frequency Counter Tektronix FCA3000 Frequency
Shunts Fluke A40B Series ACI
Resistance Standard
Guildline 9230 0.1 Ω and
0.01 Ω
DCI
Digital Multimeter Fluke 8508A Ohms, DCI, ACV, and DCV
Low Thermal Cables 5730A-7003 Various
Equipment Required for Wideband AC Module (Option 5700-03) Verification
AC Measurement Standard
Fluke 5790A with Wideband
Option -03
Wideband
Wideband Cable (supplied
with 5730A-03)
Fluke Cable Wideband
50 Ω Termination (supplied
with 5730A-03)
Fluke Termination Wideband
Adapter (supplied with
5730A-03)
Pomona 1269 BNC(F) to dual
banana plug
Wideband
Adapter (supplied with
5730A-03)
Kings KN-99-46 N(F) to
BNC(M)
Wideband
To Next Page
