5730A
Calibration Manual
76
Alternating Current Verification Test
This test checks the alternating current function by passing the current through a
shunt and measuring the voltage drop with an ac voltmeter. Use Table 17 and
Table 18 for the test record. Table 16 shows the required equipment.
Table 16. Equipment Required for AC Current Test
Equipment Model or Description
AC Measurement
standard
Fluke 5790A
Current Shunts
Fluke A40B 10 mA Shunt
Fluke A40B 20 mA Shunt
Fluke A40B 200 mA Shunt
Fluke A40B 2 A Shunt
Fluke A40B 5 A Shunt (5725A only)
Fluke A40B 10 A Shunt (5725A only)
Coaxial Cable, Type N
(M) connectors, both
ends
Fluke A40B-LEAD/N
1000 Ω Shunt See 200
μ
A Range for description
Coaxial Cable, Type N
(M) one end, dual
banana plugs other end
Fluke A40B-LEAD/4mm
BNC(F) to Dual-Banana
Plug Adapter (2
required)
Coax Cable - RG-58A/U
or RG-58C/U with
BNC(M) Connectors, 12
±1 inch long
Pomona 1269
