Fluke 5730A Calibration Manual

Multifunction Calibrator
Full Verification
75
Table 15. 5790A Adjustment Counts (cont.)
Product Range Nominal Value Measured Value Limits
22 V 20.000 00 V, 500 kHz ±24.5 mV
22 V 20.000 00 V, 1 MHz ±36 mV
220 V 200.000 0 V, 10 Hz ±59 mV
220 V 200.000 0 V, 20 Hz ±22 mV
220 V 200.000 0 V, 40 Hz ±12.7 mV
220 V 200.000 0 V, 1 kHz ±12.7 mV
220 V 200.000 0 V, 20 kHz ±12.7 mV
220 V 200.000 0 V, 50 kHz ±20.2 mV
220 V 200.000 0 V, 100 kHz ±37 mV
220 V 50 V, 300 kHz ±70 mV
220 V 30 V, 500 kHz ±206 mV
220 V 22 V, 1 MHz ± 298 mV
1000 V 250 V, 15 Hz ±100 mV
1000 V 500 V, 50 Hz ±41.5 mV
1000 V 500 V, 1 kHz ±41.5 mV
1000 V 1000 V, 50 Hz ±79 mV
1000 V 1000 V, 1 kHz ±79 mV
5725A AC Voltage Verification
1100 V 300 V, 40 Hz ±28 mV
1100 V 300 V, 1 kHz ±28 mV
1100 V 300 V, 20 kHz ±43.5 mV
1100 V 300 V, 50 kHz ±119 mV
1100 V 300 V, 100 kHz ±435 mV
1100 V 600 V, 40 Hz ±52 mV
1100 V 600 V, 1 kHz ±52 mV
1100 V 600 V, 20 kHz ±81 mV
1100 V 600 V, 50 kHz ±227 mV
1100 V 600 V, 100 kHz ±825 mV
1100 V 1000 V, 40 Hz ±84 mV
1100 V 1000 V, 1 kHz ±84 mV
1100 V 1000 V, 20 kHz ±131 mV
1100 V 1000 V, 30 kHz ±371 mV

Fluke 5730A Specifications

General

Type	Multifunction Calibrator
Resistance Range	0 to 1 GΩ
AC Voltage Frequency	10 Hz to 1 MHz
Display	Color LCD
Interfaces	RS-232, Ethernet
Weight	18 kg
DC Voltage Range	0 to ±1100 V
Dimensions	172 mm H x 432 mm W x 457 mm D (6.8 in H x 17 in W x 18 in D)
