Fluke 5790B - Page 164

5790B
Service Manual
C-14
Group DC_1000V
Name Default Function
DI_1000V 0.005 1000V range DAC volts per input volt
OF_1000V 0.0 1000V range DC offset
Group ZC_1000V
Name Default Function
Z_1000V 0.0 1000V range zero
SHO_1000V 0.0 1000V AUX input offset
IA_1000V 1000.0 1000V range A/D volts per input volt
Group AC_1000V
Name Default Function
F1_1000V 1.0 1000V range flatness correction 1 (10 Hz)
F2_1000V 1.0 1000V range flatness correction 2 (100 Hz)
F3_1000V 1.0 1000V range flatness correction 3 (1 kHz)
F4_1000V 1.0 1000V range flatness correction 4 (10 kHz)
F5_1000V 1.0 1000V range flatness correction 5 (20 kHz)
F6_1000V 1.0 1000V range flatness correction 6 (50 kHz)
F7_1000V 1.0 1000V range flatness correction 7 (100 kHz)
Group WDC_2_2MV
Name Default Function
DI_2_2MV_WB 5000.0
2_2MV range, wideband input, DAC volts per
input volt
IA_2_2MV_WB 0.0316228 2_2MV range A/D volts per input volt
