5790B
Service Manual
C-16
Group WDC_7MV
Name Default Function
DI_7MV_WB 1000.0 7MV range, wideband input, DAC volts per input volt
IA_7MV_WB 0.1 7MV range A/D volts per input volt
Group WAC_7MV
Name Default Function
F1_7MV_WB 1.0 7MV range, wideband input, flatness correction 1 (10 Hz)
F2_7MV_WB 1.0 7MV range, wideband input, flatness correction 2 (50 Hz)
F3_7MV_WB 1.0 7MV range, wideband input, flatness correction 3 (400 Hz)
F4_7MV_WB 1.0 7MV range, wideband input, flatness correction 4 (1 kHz)
F5_7MV_WB 1.0 7MV range, wideband input, flatness correction 5 (2 kHz)
F6_7MV_WB 1.0 7MV range, wideband input, flatness correction 6 (6 kHz)
F7_7MV_WB 1.0 7MV range, wideband input, flatness correction 7 (10 kHz)
F8_7MV_WB 1.0 7MV range, wideband input, flatness correction 8 (20 kHz)
F9_7MV_WB 1.0 7MV range, wideband input, flatness correction 9 (50 kHz)
F10_7MV_WB 1.0 7MV range, wideband input, flatness correction 10 (70 kHz)
F11_7MV_WB 1.0 7MV range, wideband input, flatness correction 11 (100 kHz)
F12_7MV_WB 1.0 7MV range, wideband input, flatness correction 12 (500 kHz)
F13_7MV_WB 1.0 7MV range, wideband input, flatness correction 13 (2 MHz)
F14_7MV_WB 1.0 7MV range, wideband input, flatness correction 14 (4 MHz)
F15_7MV_WB 1.0 7MV range, wideband input, flatness correction 15 (9 MHz)
F16_7MV_WB 1.0 7MV range, wideband input, flatness correction 16 (12 MHz)
F17_7MV_WB 1.0 7MV range, wideband input, flatness correction 17 (16 MHz)
F18_7MV_WB 1.0 7MV range, wideband input, flatness correction 18 (20 MHz)
F19_7MV_WB 1.0 7MV range, wideband input, flatness correction 19 (30 MHz)
F20_7MV_WB 1.0 7MV range, wideband input, flatness correction 20 (35 MHz)
F21_7MV_WB 1.0 7MV range, wideband input, flatness correction 21 (40 MHz)
F22_7MV_WB 1.0 7MV range, wideband input, flatness correction 22 (45 MHz)
F23_7MV_WB 1.0 7MV range, wideband input, flatness correction 23 (50 MHz)
