Fluke 6109A - Input Module Calibration

Portable Calibration Baths
Calibrate the Product
71
Input Module Calibration
This section provides instructions to calibrate and adjust the Input Module in the
7109A-P and 6109A-P. Table 11 lists the required equipment.
Table 11. Equipment for Input Module Calibration
Equipment Specifications Suggested Model
0 Ω 4-wire short 0.0005 Ω —
25 Ω 4-wire resistor 0.0005 Ω Fluke 742A-25
100 Ω 4-wire resistor 0.001 Ω Fluke 742A-100
200 Ω 4-wire resistor 0.002 Ω —
400 Ω 4-wire resistor 0.004 Ω —
Multifunction calibrator
mV: 2.0 μV
mA: 40 ppm + 0.4 μA
Fluke Calibration 5730A
Type E thermocouple 0.06 °C at 25 °C or 35 °C —
Calibration bath 0.1 °C at 25 °C or 35 °C
Fluke Calibration 7109A or
6109A
Reference PRT 0.008 °C Fluke Calibration 5628
PRT readout 20 ppm Fluke Calibration 1560/2560
Suitable test leads, connectors, and adapter cables are also necessary.
